B84131A0006A001 | TDK (EPCOS)
EMC filter, 50 to 60 Hz, 6 A, 250/440 VAC, faston plug 6.3 mm, B84131A0006A001
Order No.: 74D7931
EAN: 4099889078121
MPN:
B84131A0006A001
B84131A6A1
Unit Price (€ / pc.)
129.0674 € *
Standard delivery time from the manufacturer is: 11 Weeks
EMC filter, B84131A0006A001, EPCOS
4-line filter for installations and system
Features
- High insertion loss
- Compact, cost-optimized design
- Easy to install
Applications
- Power supplies
- Data system
- Telecom system
- Medical equipment
- Industrial installations
Technical specifications
| Filter | Property | Value |
|---|---|---|
| integrated switch | No | |
| Connection | faston plug 6.3 mm | |
| Rated Voltage | 250/440 VAC | |
| Number of phases | 3 | |
| With fuse | No | |
| max. operating temperature | 85 °C | |
| min. operating temperature | -25 °C | |
| Version | EMC filter | |
| max. frequency | 60 Hz | |
| min. frequency | 50 Hz | |
| Rated current | 6 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85363010 |
| Country of origin | HU |
| Original Packaging | Bulk with 8 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
