B84113H0000M060 | TDK (EPCOS)
EMC filter, 50 to 60 Hz, 6 A, 250 V (DC), 250 VAC, 3.6 mH, faston plug 6.3 mm, B84113H0000M060
Unit Price (€ / pc.)
35.3906 € *
Available: 11 pcs.
Total Price:
35.39 € *
Price list
Quantity
Price per unit*
1 pcs.
35.3906 €
5 pcs.
32.7607 €
10 pcs.
30.9162 €
25 pcs.
29.1669 €
50 pcs.
27.7746 €
*incl. VAT plus shipping costs
Subject to prior sale
EMC filter, B84113H0000M060, EPCOS
2-line filter SIFI-H for very high insertion loss
Features
- Easy to install
- Compact design
- Optimized leakage current < 0.5 mA
Applications
- Switch-mode power supplies
- Industrial electronics
- Telecommunications
- Data system
- DC applications
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 100 °C | |
| max. frequency | 60 Hz | |
| Capacity X|Y | X2 2 x 1 µF | |
| min. operating temperature | -25 °C | |
| Rated current | 6 A | |
| Connection | faston plug 6.3 mm | |
| Number of phases | 1 | |
| Rated Voltage | 250 VAC | |
| Inductance per line | 3.6 mH | |
| With fuse | No | |
| min. frequency | 50 Hz | |
| integrated switch | No | |
| Rated voltage (DC) | 250 V | |
| Version | EMC filter |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85363010 |
| Country of origin | HU |
| Original Packaging | Bulk with 24 pieces |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate |
| Date of RoHS guidelines | 3/31/15 |
