B84112G0000G125 | TDK (EPCOS)

EMC filter, 50 to 60 Hz, 25 A, 250 V (DC), 250 VAC, 1.6 mH, threaded bolt M5, B84112G0000G125

Order No.: 75D2710
EAN: 4099889080285
MPN:
B84112G0000G125
B84112GG125
Series: B84112G
B84112G0000G125 TDK (EPCOS) Interference suppression filter Image 1
B84112G0000G125 TDK (EPCOS) Interference suppression filter Image 2
Image may differ
Unit Price (€ / pc.)
57.5484 € *
Standard delivery time from the manufacturer is: 22 Weeks
Total Price:
920.77 € *
Price list
Quantity
Price per unit*
16 pcs.
57.5484 €
48 pcs.
55.4659 €
*incl. VAT plus shipping costs
Subject to prior sale

EMC filter, B84112G0000G125, EPCOS

2-line filter SIFI-G for enhanced insertion loss

Features

  • Easy to install
  • Compact design
  • Cost-optimized construction

Applications

  • Switch-mode power supplies
  • Industrial electronics
  • Telecommunications
  • Data system
  • DC applications
Technical specifications
Filter Property Value
Number of phases 1
Rated Voltage 250 VAC
min. frequency 50 Hz
min. operating temperature -25 °C
Capacity X|Y X2 2 x 1 µF, Y2 2 x 4.7 nF
Rated current 25 A
max. operating temperature 100 °C
Version EMC filter
Connection threaded bolt M5
max. frequency 60 Hz
Inductance per line 1.6 mH
Rated voltage (DC) 250 V
With fuse No
integrated switch No
Logistics
Property Value
Customs tariff number 85363010
Country of origin HU
Original Packaging Bulk with 16 pieces
Compliance
Property Value
RoHS conform Yes
Substance description Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate
SVHC free No
Date of RoHS guidelines 3/31/15
