B84110B0000A014 | TDK (EPCOS)
EMC filter, 50 to 60 Hz, 1.4 A, 250 V (DC), 250 VAC, 27 mH, PCB connection, B84110B0000A014
Unit Price (€ / pc.)
7.4256 € *
Standard delivery time from the manufacturer is: 16 Weeks
Total Price:
1,188.10 € *
Price list
Quantity
Price per unit*
160 pcs.
7.4256 €
320 pcs.
7.2114 €
*incl. VAT plus shipping costs
Subject to prior sale
EMC filter, B84110B0000A014, EPCOS
2-line filter for PCB mounting
Features
- High insertion loss
- Cost-effective EMC solution
Applications
- Low and medium switch-mode power supplies
- Data system
- Small-size equipment
- Industrial electronics
- DC applications
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (DC) | 250 V | |
| Connection | PCB connection | |
| Rated Voltage | 250 VAC | |
| Inductance per line | 27 mH | |
| Capacity X|Y | X2 2 x 150 nF | |
| Number of phases | 1 | |
| With fuse | No | |
| max. operating temperature | 100 °C | |
| min. operating temperature | -25 °C | |
| Version | EMC filter | |
| max. frequency | 60 Hz | |
| min. frequency | 50 Hz | |
| Rated current | 1.4 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85363010 |
| Country of origin | HU |
| Original Packaging | Bulk with 160 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate |
| Date of RoHS guidelines | 3/31/15 |
