B82792C2475N365 | TDK (EPCOS)
Signal line choke, SMD 1812, 4.7 mH, 300 mA, B82792C2475N365
Unit Price (€ / pc.)
3.6771 € *
Available: 160 pcs.
Total Price:
3.68 € *
Price list
Quantity
Price per unit*
1 pcs.
3.6771 €
10 pcs.
3.2368 €
100 pcs.
2.8322 €
500 pcs.
2.6180 €
1000 pcs.
2.5109 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD data and signal line chokes, type TDK/Epcos B82792C.
Can be used, for example, as current-compensated ring core choke for signal and data lines, with bifilar winding
Four-way chokes, type B82792C.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| DC current | 300 mA | |
| Tolerance | -30/+50 % | |
| Saturation current | 300 mA | |
| Design | SMD 1812 | |
| Width | 10.5 mm | |
| Height | 7.3 mm | |
| Inductance | 4.7 mH | |
| Version | signal line choke | |
| Length | 11.5 mm | |
| DC resistance | 700 mΩ | |
| Measuring frequency | 10 kHz |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| Country of origin | RO |
| Original Packaging | Reel with 500 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
