B82792C2105N365 | TDK (EPCOS)
Signal line choke, SMD 1812, 1 mH, 500 mA, B82792C2105N365
Order No.: 73D9294
EAN: 4099889007640
MPN:
B82792C2105N365
Unit Price (€ / pc.)
3.1297 € *
Standard delivery time from the manufacturer is: 28 Weeks
SMD data and signal line chokes, type TDK/Epcos B82792C.
Can be used, for example, as current-compensated ring core choke for signal and data lines, with bifilar winding
Four-way chokes, type B82792C.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inductance | 1 mH | |
| Length | 11.5 mm | |
| Saturation current | 500 mA | |
| Design | SMD 1812 | |
| DC resistance | 170 mΩ | |
| Tolerance | -30/+50 % | |
| DC current | 500 mA | |
| Width | 10.5 mm | |
| Measuring frequency | 10 kHz | |
| Height | 7.3 mm | |
| Version | signal line choke |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Original Packaging | Reel with 500 pieces |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
