B82767S4263N030 | TDK (EPCOS)

Power line choke, radial, 430 µH, 26 A, B82767S4263N030

Order No.: 74D7808
EAN: 4099889026399
MPN:
B82767S4263N030
B82767S4263N30
TDK (EPCOS)
B82767S4263N030 TDK (EPCOS) Fixed Inductors
Image may differ
Print
Key Specification:
Version power line choke
Inductance 430 µH
DC current 26 A
Tolerance ±30 %
DC resistance 1.5 mΩ
Download Datasheet Technical specifications
Unit Price (€ / pc.)
15.4105 € *
Standard delivery time from the manufacturer is: 16 Weeks
Total Price:
1,725.98 € *
*incl. VAT plus shipping costs
Subject to prior sale
112 pcs.
15.4105 €
Description
Technical specifications
Download
Logistics
Compliance

Power line choke, B82767S4263N030, EPCOS

Features

  • High resonance frequency
  • High rated current and rated temperature
  • Suitable for wave soldering
  • No adhesives used
  • RoHS-compatible

Applications

  • Suppression of common-mode interferences
  • Switch-mode applications
  • Power inverters
  • Frequency converters
Technical specifications
DC current 26 A
Width 60 mm
Height 33 mm
Length 60 mm
DC resistance 1.5 mΩ
Measuring frequency 100 kHz
Version power line choke
Design radial
Tolerance ±30 %
Inductance 430 µH
Articles of same specification 0
Logistics
Customs tariff number 85045000
Original Packaging Carton with 28 pieces
Compliance
Date of RoHS guidelines 3/31/15
Substance description Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate
SVHC free No
RoHS conform Yes
