B82767S4123N030 | TDK (EPCOS)
Power line choke, radial, 1.45 mH, 12 A, B82767S4123N030
Order No.: 74D7806
EAN: 4099889026375
MPN:
B82767S4123N030
B82767S4123N30
Unit Price (€ / pc.)
14.0182 € *
Standard delivery time from the manufacturer is: 18 Weeks
Power line choke, B82767S4123N030, EPCOS
Features
- High resonance frequency
- High rated current and rated temperature
- Suitable for wave soldering
- No adhesives used
- RoHS-compatible
Applications
- Suppression of common-mode interferences
- Switch-mode applications
- Power inverters
- Frequency converters
Technical specifications
| Filter | Property | Value |
|---|---|---|
| DC current | 12 A | |
| Tolerance | ±30 % | |
| Design | radial | |
| Width | 60 mm | |
| Height | 33 mm | |
| Inductance | 1.45 mH | |
| Version | power line choke | |
| Length | 60 mm | |
| DC resistance | 7.1 mΩ | |
| Measuring frequency | 10 kHz |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| Original Packaging | Carton with 28 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate |
| Date of RoHS guidelines | 3/31/15 |
