B82747S4303A041 | TDK (EPCOS)
Power line choke, radial, 820 µH, 35 A, B82747S4303A041
Order No.: 74D7803
EAN: 4099889026344
MPN:
B82747S4303A041
B82747S4303A41
Unit Price (€ / pc.)
15.5890 € *
Standard delivery time from the manufacturer is: 18 Weeks
Power line choke, B82747S4303A041, EPCOS
Features
- Approx. 0.5 - 0.65 % stray inductance for symmetrical interference suppression
- Suitable for wave soldering
- Design complies with EN 60938-2
- High resonance frequency
- RoHS-compatible
Applications
- Suppression of common-mode interferences
- Switch-mode power applications
- Power inverters
- Frequency converters
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Tolerance | ±30 % | |
| Width | 64 mm | |
| Version | power line choke | |
| DC current | 35 A | |
| Length | 64 mm | |
| Height | 35 mm | |
| DC resistance | 1.4 mΩ | |
| Design | radial | |
| Measuring frequency | 100 kHz | |
| Inductance | 820 µH |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Carton with 28 pieces |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| Substance description | Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
