B82725A2123N040 | TDK (EPCOS)

Power line choke, radial, 3.3 mH, 12 A, B82725A2123N040

Order No.: 74D7689
EAN: 4099889025576
MPN:
B82725A2123N040
B82725A2123N40
TDK (EPCOS)
B82725A2123N040 TDK (EPCOS) Fixed Inductors
Image may differ
Print
Key Specification:
Version power line choke
Inductance 3.3 mH
DC current 12 A
Tolerance ±30 %
DC resistance 12 mΩ
Download Datasheet Technical specifications
Unit Price (€ / pc.)
5.2836 € *
Standard delivery time from the manufacturer is: 8 Weeks
Total Price:
1,690.75 € *
*incl. VAT plus shipping costs
Subject to prior sale
320 pcs.
5.2836 €
Description
Technical specifications
Download
Logistics
Compliance

Power line choke, B82725A2123N040, EPCOS

Features

  • High resonance frequency due to special winding technique
  • Suitable for wave soldering
  • Design complies with EN 60938-2
  • Approx. 1% stray inductance for symmetrical interference suppression
  • RoHS-compatible

Applications

  • Suppression of common-mode interferences
  • Switch-mode power applications
  • Electronic ballasts in lamps
  • Power inverters
Technical specifications
Inductance 3.3 mH
DC current 12 A
Width 42.4 mm
Length 44 mm
Design radial
DC resistance 12 mΩ
Version power line choke
Height 25 mm
Tolerance ±30 %
Measuring frequency 10 kHz
Articles of same specification 0
Logistics
Country of origin HU
Customs tariff number 85045000
Original Packaging Carton with 160 pieces
Compliance
RoHS conform Yes
Substance description Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate
SVHC free No
Date of RoHS guidelines 3/31/15
