B82725A2102N001 | TDK (EPCOS)
Power line choke, radial, 68 mH, 1 A, B82725A2102N001
Order No.: 74D7686
EAN: 4099889025545
MPN:
B82725A2102N001
B82725A2102N1
Unit Price (€ / pc.)
5.0813 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
Power line choke, B82725A2102N001, EPCOS
Features
- High resonance frequency due to special winding technique
- Suitable for wave soldering
- Design complies with EN 60938-2
- Approx. 1% stray inductance for symmetrical interference suppression
- RoHS-compatible
Applications
- Suppression of common-mode interferences
- Switch-mode power applications
- Electronic ballasts in lamps
- Power inverters
Technical specifications
| DC current | 1 A | |
| Width | 42.4 mm | |
| Height | 25 mm | |
| Length | 44 mm | |
| DC resistance | 1.3 Ω | |
| Measuring frequency | 10 kHz | |
| Version | power line choke | |
| Design | radial | |
| Tolerance | ±30 % | |
| Inductance | 68 mH |
Download
Logistics
| Country of origin | HU |
| Customs tariff number | 85045000 |
| Original Packaging | Carton with 160 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate |
| SVHC free | No |
| RoHS conform | Yes |
