B82623G0001A010 | TDK (EPCOS)

Power line choke, SMD, 82 µH, 2 A, B82623G0001A010

Order No.: 74D7536
EAN: 4099889024357
MPN:
B82623G0001A010
B82623G1A10
TDK (EPCOS)
B82623G0001A010 TDK (EPCOS) Fixed Inductors
Image may differ
Print
Key Specification:
Version power line choke
Inductance 82 µH
DC current 2 A
Tolerance ±20 %
DC resistance 100 mΩ
Download Datasheet Technical specifications
Unit Price (€ / pc.)
2.3205 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
Total Price:
1,856.40 € *
*incl. VAT plus shipping costs
**Subject to prior sale
800 pcs.
2.3205 €
Description
Technical specifications
Download
Logistics
Compliance

Power line choke, B82623G0001A010, EPCOS

Features

  • Effective suppression of differential-mode interferences at higher frequencies
  • Suitable for wave soldering
  • Design complies with EN 60938-2
  • RoHS-compatible

Applications

  • Suppression of differential-mode interferences
  • Compact switch-mode applications
  • Reduction of harmonics and PFC
Technical specifications
DC current 2 A
Width 27 mm
Height 16.8 mm
Length 28 mm
DC resistance 100 mΩ
Measuring frequency 100 kHz
Version power line choke
Design SMD
Tolerance ±20 %
Inductance 82 µH
Articles of same specification 0
Logistics
Country of origin HU
Customs tariff number 85045000
Original Packaging Bulk with 400 pieces
Compliance
Date of RoHS guidelines 3/31/15
Substance description Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate
SVHC free No
RoHS conform Yes
