B82498B3470J000 | TDK (EPCOS)
Choke, SMD 0805, 47 nH, 500 mA, B82498B3470J000
Not suitable for new designs
Unit Price (€ / pc.)
0.6783 € *
Available: 4,515 pcs.
Total Price:
0.68 € *
Price list
Quantity
Price per unit*
1 pcs.
0.6783 €
25 pcs.
0.5355 €
100 pcs.
0.4522 €
250 pcs.
0.3927 €
1000 pcs.
0.3451 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD choke, B82498B3470J000, EPCOS
Features
- High Q factor
- High resonance frequency
- Suitable for lead-free reflow soldering
- Close inductance tolerance
Applications
- Antenna amplifiers
- Car access systems
- TPMS (Tire Pressure Monitoring System)
- GPS (Global Positioning System)
- Wireless communication systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| DC current | 500 mA | |
| Inductance | 47 nH | |
| DC resistance | 0.13 Ω | |
| Version | SMD choke | |
| Width | 1.45 mm | |
| Quality Q | Q 45 | |
| Measuring frequency | 200 MHz | |
| Height | 1.4 mm | |
| Tolerance | ±5 % | |
| Design | SMD 0805 | |
| Length | 2.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85045000 |
| Original Packaging | Bulk with 3,000 pieces |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
