B82498B1102J000 | TDK (EPCOS)
Choke, SMD 0805, 1 µH, 250 mA, B82498B1102J000
Unit Price (€ / pc.)
0.7735 € *
Available: 2,649 pcs.
Total Price:
0.77 € *
Price list
Quantity
Price per unit*
1 pcs.
0.7735 €
25 pcs.
0.6307 €
100 pcs.
0.5236 €
250 pcs.
0.4522 €
1000 pcs.
0.4046 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD choke, B82498B1102J000, EPCOS
Features
- High Q factor
- High resonance frequency
- Suitable for lead-free reflow soldering
- Close inductance tolerance
Applications
- Antenna amplifiers
- Car access systems
- TPMS (Tire Pressure Monitoring System)
- GPS (Global Positioning System)
- Wireless communication systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| DC current | 250 mA | |
| Inductance | 1 µH | |
| DC resistance | 0.5 Ω | |
| Version | SMD choke | |
| Width | 1.45 mm | |
| Quality Q | Q 20 | |
| Measuring frequency | 7.96 MHz | |
| Height | 1.4 mm | |
| Tolerance | ±5 % | |
| Design | SMD 0805 | |
| Length | 2.2 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85045000 |
| Original Packaging | Bulk with 3,000 pieces |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
