B82477G4823M000 | TDK (EPCOS)
Power choke, SMD, 82 µH, 1.9 A, B82477G4823M000
Order No.: 74D7273
EAN: 4099889022568
MPN:
B82477G4823M000
B82477G4823M
Unit Price (€ / pc.)
1.0115 € *
Standard delivery time from the manufacturer is: 26 Weeks
Power inductor, B82477G4823M000, EPCOS
Features
- Temperature range up to +125 °C
- Very high rated current
- Suitable for lead-free reflow soldering
- RoHS-compatible
Applications
- EDP (Electronic Data Processing)
- Consumer electronics
- DC/DC converters
- Industrial electronics
Technical specifications
Filter | Property | Value |
---|---|---|
DC current | 1.9 A | |
Saturation current | 2.25 A | |
Width | 12.8 mm | |
Height | 8 mm | |
Length | 12.8 mm | |
DC resistance | 145 mΩ | |
Measuring frequency | 100 kHz | |
Version | power choke | |
Design | SMD | |
Tolerance | ±20 % | |
Inductance | 82 µH |
Download
Logistics
Property | Value |
---|---|
Country of origin | CN |
Customs tariff number | 85045000 |
Original Packaging | Bulk with 400 pieces |
Compliance
Property | Value |
---|---|
Date of RoHS guidelines | 3/31/15 |
SVHC free | Yes |
RoHS conform | Yes |
