B82477G2104M000 | TDK (EPCOS)
Power choke, SMD, 100 µH, 1.3 A, B82477G2104M000
Unit Price (€ / pc.)
1.0472 € *
Available: 49 pcs.
Total Price:
10.47 € *
Price list
Quantity
Price per unit*
10 pcs.
1.0472 €
50 pcs.
0.9282 €
600 pcs.
0.7378 €
1200 pcs.
0.6902 €
2400 pcs.
0.6426 €
*incl. VAT plus shipping costs
Subject to prior sale
SMT power inductors, type TDK/Epcos B82477G2./G4.
For high rated currents, low DC resistance. Magnetically shielded case
Size 12.3 x 12.3 x 6.0 mm, type B82477G2.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inductance | 100 µH | |
| DC current | 1.3 A | |
| Width | 12.3 mm | |
| Length | 12.3 mm | |
| Design | SMD | |
| DC resistance | 160 mΩ | |
| Version | power choke | |
| Height | 6 mm | |
| Tolerance | ±20 % | |
| Measuring frequency | 1 kHz |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85045000 |
| Original Packaging | Bulk with 600 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
