B82472G6682M000 | TDK (EPCOS)

Power choke, SMD, 6.8 µH, 2.15 A, B82472G6682M000

Order No.: 73D9130
EAN: 4099889007015
MPN:
B82472G6682M000
B82472G6682M
Series: B82472G6
B82472G6682M000 TDK (EPCOS) Fixed Inductors Image 1
B82472G6682M000 TDK (EPCOS) Fixed Inductors Image 2
Image may differ
Unit Price (€ / pc.)
0.6545 € *
Standard delivery time from the manufacturer is: 24 Weeks
Total Price:
654.50 € *
*incl. VAT plus shipping costs
Subject to prior sale
1000 pcs.
0.6545 €

Power inductor, B82472G6682M000, EPCOS

Features

  • Temperature range up to +125 °C
  • High rated current
  • Suitable for lead-free reflow soldering
  • RoHS-compatible

Applications

  • Filtering of supply voltages
  • Coupling and decoupling
  • DC/DC converters
  • Consumer electronics
Technical specifications
Filter Property Value
Inductance 6.8 µH
DC current 2.15 A
DC resistance 0.04 Ω
Design SMD
Version power choke
Width 7.3 mm
Height 4.5 mm
Saturation current 1.7 A
Tolerance ±20 %
Measuring frequency 100 kHz
Length 7.3 mm
Logistics
Property Value
Country of origin CN
Original Packaging Bulk with 1,000 pieces
Customs tariff number 85045000
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
