B82464G4334M000 | TDK (EPCOS)
Power choke, SMD, 330 µH, 590 mA, B82464G4334M000
Unit Price (€ / pc.)
2.0468 € *
Available: 7 pcs.
Total Price:
2.05 € *
Price list
Quantity
Price per unit*
1 pcs.
2.0468 €
10 pcs.
1.6541 €
100 pcs.
1.3923 €
250 pcs.
1.2019 €
1000 pcs.
1.0591 €
*incl. VAT plus shipping costs
Subject to prior sale
Power inductor, B82464G4334M000, EPCOS
Features
- Temperature range up to +150 °C
- High rated current
- Suitable for lead-free reflow soldering
- RoHS-compatible
Applications
- Filtering of supply voltages
- Coupling and decoupling
- DC/DC converters
- Automotive electronics
- Industrial electronics
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Height | 4.8 mm | |
| Length | 10.4 mm | |
| DC current | 590 mA | |
| Saturation current | 650 mA | |
| Measuring frequency | 100 kHz | |
| Inductance | 330 µH | |
| Version | power choke | |
| DC resistance | 0.65 Ω | |
| Width | 10.4 mm | |
| Design | SMD | |
| Tolerance | ±20 % |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | HU |
| Original Packaging | Bulk with 750 pieces |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
