B82464G4224M000 | TDK (EPCOS)
Power choke, SMD, 220 µH, 700 mA, B82464G4224M000
Unit Price (€ / pc.)
1.7493 € *
Available: 12 pcs.
Total Price:
5.25 € *
Price list
Quantity
Price per unit*
3 pcs.
1.7493 €
25 pcs.
1.5351 €
150 pcs.
1.3566 €
500 pcs.
1.2257 €
1000 pcs.
1.1186 €
*incl. VAT plus shipping costs
Subject to prior sale
Power inductor, B82464G4224M000, EPCOS
Features
- Temperature range up to +150 °C
- High rated current
- Suitable for lead-free reflow soldering
- RoHS-compatible
Applications
- Filtering of supply voltages, coupling, decoupling
- DC/DC converters
- Industrial electronics
- Automotive electronics
Technical specifications
| Filter | Property | Value |
|---|---|---|
| DC current | 700 mA | |
| DC resistance | 0.44 Ω | |
| Saturation current | 750 mA | |
| Measuring frequency | 100 kHz | |
| Tolerance | ±20 % | |
| Length | 10.4 mm | |
| Height | 4.8 mm | |
| Width | 10.4 mm | |
| Inductance | 220 µH | |
| Design | SMD | |
| Version | power choke |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | HU |
| Original Packaging | Bulk with 750 pieces |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
