B82442T1103K050 | TDK (EPCOS)
Choke, SMD 2220, 10 µH, 1.42 A, B82442T1103K050
Unit Price (€ / pc.)
0.7259 € *
Standard delivery time from the manufacturer is: On Request
SMD Power inductor, B82442T1103K050, EPCOS
The B82442T1103K050 is an inductor that blocks all high frequency RF signals and only allows DC signals to pass through it.
Features
- Temperature range up to +150 °C
- High Q factor
- Qualified to AEC-Q200
- Suitable for lead-free reflow soldering as referenced in JEDEC J-STD 020D
- RoHS-compatible
Applications
- Filtering of supply voltages, coupling, decoupling
- Antenna systems
- Automotive electronics
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | SMD choke | |
| Inductance | 10 µH | |
| DC current | 1.42 A | |
| Tolerance | ±10 % | |
| DC resistance | 132 mΩ | |
| Saturation current | 2.28 A | |
| Measuring frequency | 2.52 MHz | |
| Quality Q | Q 15 | |
| Design | SMD 2220 | |
| Length | 5.6 mm | |
| Width | 5 mm | |
| Height | 5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | HU |
| Customs tariff number | 85045000 |
| Original Packaging | Reel with 1,500 pieces |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
