B82432C1683K000 | TDK (EPCOS)

Choke, SMD 1812, 68 µH, 190 mA, B82432C1683K000

Order No.: 76D9618
EAN: 4099889045994
MPN:
B82432C1683K000
B82432C1683K
B82432C1683K000 TDK (EPCOS) Fixed Inductors Image 1
B82432C1683K000 TDK (EPCOS) Fixed Inductors Image 2
Image may differ
Unit Price (€ / pc.)
0.4879 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
2,439.50 € *
*incl. VAT plus shipping costs
Subject to prior sale
5000 pcs.
0.4879 €

SMD choke, B82432C1683K000, EPCOS

Features

  • Temperature range up to +150 °C
  • High Q factor
  • Suitable for lead-free reflow soldering
  • RoHS-compatible

Applications

  • Filtering of supply voltages, coupling, decoupling
  • Antenna systems
  • Telecommunications
  • Automotive electronics
Technical specifications
Filter Property Value
Inductance 68 µH
DC current 190 mA
Width 3.2 mm
Quality Q Q 30
Length 4.5 mm
Design SMD 1812
DC resistance 2.8 Ω
Version SMD choke
Height 3.2 mm
Tolerance ±10 %
Measuring frequency 100 kHz
Logistics
Property Value
Country of origin DE
Customs tariff number 85045000
Original Packaging Bulk with 2,500 pieces
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
