B82432C1224K000 | TDK (EPCOS)
Choke, SMD 1812, 220 µH, 115 mA, B82432C1224K000
Unit Price (€ / pc.)
0.7057 € *
Available: 4,800 pcs.
Total Price:
0.71 € *
Price list
Quantity
Price per unit*
1 pcs.
0.7057 €
10 pcs.
0.5771 €
100 pcs.
0.4748 €
500 pcs.
0.4141 €
1000 pcs.
0.3915 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD Power inductor, B82432C1224K000, EPCOS
The B82432C1224K000 is an inductor that blocks all high frequency RF signals and only allows DC signals to pass through it.
Features
- Temperature range up to +150 °C
- High Q factor
- Qualified to AEC-Q200
- Suitable for lead-free reflow soldering as referenced in JEDEC J-STD 020D
- RoHS-compatible
Applications
- Filtering of supply voltages, coupling, decoupling
- Antenna systems
- Automotive electronics
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Width | 3.2 mm | |
| Quality Q | Q 30 | |
| DC resistance | 7.5 Ω | |
| Tolerance | ±10 % | |
| DC current | 115 mA | |
| Measuring frequency | 100 kHz | |
| Version | SMD choke | |
| Design | SMD 1812 | |
| Height | 3.2 mm | |
| Length | 4.5 mm | |
| Inductance | 220 µH |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bulk with 2,500 pieces |
| Country of origin | HU |
| Customs tariff number | 85045000 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
