B78148S1472K000 | TDK (EPCOS)
RF choke, radial, 4.7 µH, 820 mA, B78148S1472K000
Order No.: 74D6176
EAN: 4099889015126
MPN:
B78148S1472K000
B78148S1472K
Unit Price (€ / pc.)
0.1999 € *
Standard delivery time from the manufacturer is: 6 Weeks
RF inductor, B78148S1472K000, EPCOS
Features
- Wide inductance range
- Suitable for general-purpose application
- Suitable for wave soldering
- RoHS-compatible
Applications
- RF blocking and filtering
- Decoupling and interference suppression
- Automotive electronics
- Antenna systems
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Quality Q | Q 60 | |
| DC current | 820 mA | |
| Length | 9.2 mm | |
| DC resistance | 340 mΩ | |
| Measuring frequency | 1 MHz | |
| Version | RF choke | |
| Design | radial | |
| Tolerance | ±10 % | |
| Inductance | 4.7 µH |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85045000 |
| Original Packaging | Bulk with 2,000 pieces |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
