B81123C1103M189 | TDK (EPCOS)

Name: MKP suppression capacitor, 10 nF, ±20 %, 500 V (AC), PP, 22.5 mm, B81123C1103M189
Brand: TDK (EPCOS)
SKU: 74D6243
Availability: InStock

MKP suppression capacitor, 10 nF, ±20 %, 500 V (AC), PP, 22.5 mm, B81123C1103M189

Order No.: 74D6243

EAN: 4099879863317

MPN:

B81123C1103M189

Image may differ

Key Specification:

Capacity 10 nF

Rated voltage (AC) 500 V

Tolerance ±20 %

Dielectric material PP

Download Datasheet Technical specifications

Unit Price (€ / pc.)

1.071 € *

Standard delivery time from the manufacturer is: 10 Weeks

Total Price:

1,713.60 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Film capacitor, B81123C1103M189, EPCOS

EMI suppression capacitor (MKP)

Features

Self-healing properties
RoHS-compatible

Applications

Y1 class for interference suppression
Line to ground
Double insulation

Technical specifications

Filter	Property	Value
	Grid	22.5 mm
	Height	18.5 mm
	min. operating temperature	-40 °C
	max. operating temperature	110 °C
	Rated voltage (AC)	500 V
	Tolerance	±20 %
	Width	10.5 mm
	Interference suppression class	Y1
	Capacity	10 nF
	Design	radial
	Length	26.5 mm
	Number of pins	2
	Dielectric material	PP
