B33331V7506J080 | TDK (EPCOS)

MKP film capacitor, 50 µF, ±5 %, 650 V (DC), PP, B33331V7506J080

Order No.: 45D8932
EAN: 4099879853479
MPN:
B33331V7506J080
B33331V7506J 80
TDK (EPCOS)
B33331V7506J080 TDK (EPCOS) Film Capacitors
Image may differ
Print
Key Specification:
Capacity 50 µF
Rated voltage (DC) 650 V
Rated voltage (AC) 460 V
Tolerance ±5 %
Dielectric material PP
Download Datasheet Technical specifications
Unit Price (€ / pc.)
10.115 € *
Standard delivery time from the manufacturer is: 13 Weeks
Total Price:
1,456.56 € *
*incl. VAT plus shipping costs
Subject to prior sale
144 pcs.
10.115 €
Description
Technical specifications
Download
Logistics
Compliance

Motor run capacitor, B33331V7506J080, EPCOS

Film capacitor - AC capacitor

Features

  • Self-healing properties
  • Low dissipation factor
  • Overpressure disconnection safety device
  • S2 safety
  • High insulation resistance

Applications

  • For general sine wave application, mainly as motor run
Technical specifications
Rated voltage (DC) 650 V
Dielectric material PP
Capacity 50 µF
Height 100 mm
Rated voltage (AC) 460 V
Design can
min. operating temperature -40 °C
Tolerance ±5 %
max. operating temperature 85 °C
Number of pins 2
Articles of same specification 0
Logistics
Customs tariff number 85321000
Original Packaging Carton with 36 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
