B33331B6166J080 | TDK (EPCOS)
Motor operating capacitor, 16 µF, ±5 %, 450 V (AC), PP, B33331B6166J080
Unit Price (€ / pc.)
10.6743 € *
Available: 14 pcs.
Total Price:
10.67 € *
Price list
Quantity
Price per unit*
1 pcs.
10.6743 €
10 pcs.
9.3891 €
49 pcs.
8.7584 €
196 pcs.
8.2586 €
392 pcs.
7.9373 €
*incl. VAT plus shipping costs
Subject to prior sale
Motor run capacitor, B33331B6166J080, EPCOS
Features
- Self-healing properties
- Low dissipation factor
- Overpressure disconnection safety device
- S2 safety class as per IEC-60252-1(ed-2) am1
- High insulation resistance
- EN 60335-1 compliance
Applications
- For general sine wave application, mainly as motor run
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage (AC) | 450 V | |
| Height | 75 mm | |
| Number of pins | 2 | |
| Capacity | 16 µF | |
| Design | can | |
| min. operating temperature | -40 °C | |
| Dielectric material | PP | |
| Tolerance | ±5 % | |
| max. operating temperature | 85 °C |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Carton with 49 pieces |
| Customs tariff number | 85321000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
