B32776G0146K000 | TDK (EPCOS)
MKP film capacitor, 14 µF, ±10 %, 1.1 kV (DC), PP, 37.5 mm, B32776G0146K000
Order No.: 37D1490
EAN: 4099879815101
MPN:
B32776G0146K000
B32776G146K
Unit Price (€ / pc.)
5.5692 € *
Standard delivery time from the manufacturer is: 6 Weeks
Film capacitor (MKP), type TDK/Epcos B32774../B32776../B32778.
With 2 or 4 connecting wires
Rated voltage 1100 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Width | 28 mm | |
| Rated voltage (DC) | 1.1 kV | |
| Number of pins | 4 | |
| Length | 42 mm | |
| Design | radial | |
| Dielectric material | PP | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -40 °C | |
| Height | 37 mm | |
| Capacity | 14 µF | |
| Tolerance | ±10 % | |
| Grid | 37.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | ES |
| Customs tariff number | 85321000 |
| Original Packaging | Bulk with 110 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
