B32758G2556K000 | TDK (EPCOS)

Name: MKP film capacitor, 55 µF, ±10 %, 500 V (DC), PP, 52.5 mm, B32758G2556K000
Brand: TDK (EPCOS)
SKU: 53D5116
Availability: InStock

MKP film capacitor, 55 µF, ±10 %, 500 V (DC), PP, 52.5 mm, B32758G2556K000

Order No.: 53D5116

EAN: 4099879860934

MPN:

B32758G2556K000

Image may differ

Key Specification:

Capacity 55 µF

Rated voltage (DC) 500 V

Rated voltage (AC) 250 V

Tolerance ±10 %

Dielectric material PP

Download Datasheet Technical specifications

Unit Price (€ / pc.)

14.9821 € *

Standard delivery time from the manufacturer is: 6 Weeks

Total Price:

1,438.28 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Film capacitor, B32758G2556K000, EPCOS

Metallized polypropylene film capacitor (MKP)

Features

Optimized AC voltage performance
High ripple current/frequency handling capability
UL 810 construction
For PCB mounting

Applications

Output AC filtering for power converters, UPS, motor drives

Technical specifications

Filter	Property	Value
	Grid	52.5 mm
	Height	57.5 mm
	min. operating temperature	-40 °C
	max. operating temperature	105 °C
	Rated voltage (AC)	250 V
	Rated voltage (DC)	500 V
	Tolerance	±10 %
	Width	38 mm
	Capacity	55 µF
	Design	radial
	Length	57.5 mm
	Number of pins	4
	Dielectric material	PP
