B32756G7226K000 | TDK (EPCOS)

Name: MKP film capacitor, 22 µF, ±10 %, 550 V (DC), PP, 37.5 mm, B32756G7226K000
Brand: TDK (EPCOS)
SKU: 53D5104
Availability: InStock

MKP film capacitor, 22 µF, ±10 %, 550 V (DC), PP, 37.5 mm, B32756G7226K000

Order No.: 53D5104

EAN: 4099879860897

MPN:

B32756G7226K000

Image may differ

Key Specification:

Capacity 22 µF

Rated voltage (DC) 550 V

Rated voltage (AC) 275 V

Tolerance ±10 %

Dielectric material PP

Download Datasheet Technical specifications

Unit Price (€ / pc.)

9.6271 € *

Standard delivery time from the manufacturer is: 999 Weeks

Total Price:

1,732.88 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Film capacitor, B32756G7226K000, EPCOS

Metallized polypropylene film capacitor (MKP)

Features

Optimized AC voltage performance
High ripple current/frequency handling capability
UL 810 construction
For PCB mounting

Applications

Output AC filtering for power converters, UPS, motor drives

Technical specifications

Filter	Property	Value
	Grid	37.5 mm
	Rated voltage (DC)	550 V
	max. operating temperature	105 °C
	Number of pins	4
	Rated voltage (AC)	275 V
	Tolerance	±10 %
	Length	42 mm
	Capacity	22 µF
	Dielectric material	PP
	Height	48 mm
	Width	33 mm
	min. operating temperature	-40 °C
	Design	radial
