B32686S7224J564 | TDK (EPCOS)

MFP film capacitor, 220 nF, ±5 %, 1.25 kV (DC), PP, 28.5 mm, B32686S7224J564

Order No.: 45D5142
EAN: 4099879848680
MPN:
B32686S7224J564
B32686S7224J564 TDK (EPCOS) Film Capacitors
Image may differ
Unit Price (€ / pc.)
9.4724 € *
Standard delivery time from the manufacturer is: 22 Weeks
Total Price:
1,212.47 € *
*incl. VAT plus shipping costs
Subject to prior sale
128 pcs.
9.4724 €

Film capacitor, B32686S7224J564, EPCOS

Metallized polypropylene film capacitor (MFP)

Features

  • Very high pulse strength
  • Highest possible contact reliability
  • High current
  • RoHS-compatible

Applications

  • Snubbering
  • Filtering
  • IGBT
Technical specifications
Filter Property Value
Width 18 mm
Rated voltage (AC) 450 V
Rated voltage (DC) 1.25 kV
Number of pins 2
Length 42 mm
Design radial
Dielectric material PP
max. operating temperature 110 °C
min. operating temperature -55 °C
Height 32.5 mm
Capacity 220 nF
Tolerance ±5 %
Grid 28.5 mm
Logistics
Property Value
Country of origin BR
Customs tariff number 85321000
Original Packaging Bulk with 32 pieces
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
