B32529E6473K289 | TDK (EPCOS)
MKT film capacitor, 47 nF, ±10 %, 400 V (DC), PET, 5 mm, B32529E6473K289
Not suitable for new designs
Unit Price (€ / pc.)
0.7616 € *
Standard delivery time from the manufacturer is: 24 Weeks
Film capacitor (MKT), type TDK/Epcos B3252.
Self-sealing, radial connections
Rated voltage 400 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 5 mm | |
| Rated voltage (DC) | 400 V | |
| max. operating temperature | 125 °C | |
| Number of pins | 2 | |
| Rated voltage (AC) | 200 V | |
| Tolerance | ±10 % | |
| Length | 7.3 mm | |
| Capacity | 47 nF | |
| Dielectric material | PET | |
| Height | 9.5 mm | |
| Width | 4.5 mm | |
| min. operating temperature | -55 °C | |
| Design | radial |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | BR |
| Original Packaging | Ammopack with 1,800 pieces |
| Customs tariff number | 85321000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
