B32344E4152A010 | TDK (EPCOS)
MKP film capacitor, 92 µF, -5/+10 %, 415 V (AC), PP, B32344E4152A010
Order No.: 45D0634
EAN: 4099879824103
MPN:
B32344E4152A010
B32344E4152A10
Unit Price (€ / pc.)
85.442 € *
Standard delivery time from the manufacturer is: 9 Weeks
PhiCap capacitor, B32344E4152A010, EPCOS
Film capacitor - Power factor correction
Features
- Three-phase, delta connected
- Self-healing technology
- Naturally air cooled (or forced air cooling)
- Indoor mounting
Applications
- For Power Factor Correction
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Dielectric material | PP | |
| Capacity | 92 µF | |
| Height | 273 mm | |
| Rated voltage (AC) | 415 V | |
| Design | can | |
| min. operating temperature | -40 °C | |
| Tolerance | -5/+10 % | |
| max. operating temperature | 85 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85321000 |
| Original Packaging | Carton with 1 piece |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| Substance description | Lead |
| SVHC free | No |
| RoHS conform | Yes |
