B32332I6606J082 | TDK (EPCOS)
Film capacitor, 60 µF, ±5 %, 450 V (AC), PP, B32332I6606J082
Order No.: 46D0033
EAN: 4099879853592
MPN:
B32332I6606J082
B32332I6606J82
Unit Price (€ / pc.)
18.207 € *
Standard delivery time from the manufacturer is: 10 Weeks
AC film capacitor, B32332I6506J082, EPCOS
Features
- Self-healing properties
- Low dissipation factor
- Overpressure disconnection safety device
- S2 safety class as per IEC-60252-1(ed-2) am1
- High insulation resistance
- EN 60335-1 compliance on request
Applications
- For general sine wave application, mainly as motor run
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 85 °C | |
| Rated voltage (AC) | 450 V | |
| Tolerance | ±5 % | |
| Capacity | 60 µF | |
| Dielectric material | PP | |
| Height | 103 mm | |
| min. operating temperature | -25 °C | |
| Design | can |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Carton with 25 pieces |
| Customs tariff number | 85321000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
