B32332I6406J081 | TDK (EPCOS)
Film capacitor, 40 µF, ±5 %, 450 V (AC), PP, B32332I6406J081
Order No.: 46D0027
EAN: 4099879853561
MPN:
B32332I6406J081
B32332I6406J81
Unit Price (€ / pc.)
13.3994 € *
Standard delivery time from the manufacturer is: 10 Weeks
Motor run capacitor, B32332I6406J081, EPCOS
Film capacitor - AC capacitor
Features
- Self-healing properties
- Low dissipation factor
- Overpressure disconnection safety device
- High insulation resistance
Applications
- For general sine wave application, mainly as motor run
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 85 °C | |
| Rated voltage (AC) | 450 V | |
| Tolerance | ±5 % | |
| Capacity | 40 µF | |
| Dielectric material | PP | |
| Height | 103 mm | |
| min. operating temperature | -25 °C | |
| Design | can |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Carton with 36 pieces |
| Customs tariff number | 85321000 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
