B66335G1500X127 | TDK (EPCOS)

E core, N27, 364 nH, (L x W x H) 55 x 27.8 x 21 mm, B66335G1500X127

Order No.: 83D946
EAN: 4099889059717
MPN:
B66335G1500X127
Series: B663x
B66335G1500X127 TDK (EPCOS) Ferrite cores Image 1
B66335G1500X127 TDK (EPCOS) Ferrite cores Image 2
Image may differ
Unit Price (€ / pc.)
4.9623 € *
Available: 348 pcs.
Total Price:
4.96 € *
Price list
Quantity
Price per unit*
1 pcs.
4.9623 €
10 pcs.
4.3673 €
108 pcs.
3.8437 €
216 pcs.
3.6890 €
864 pcs.
3.4510 €
*incl. VAT plus shipping costs
Subject to prior sale

E cores E55/28/21, type TDK/Epcos B66335.

To IEC 61246. Made of silicon ferrite materials; refer to the corresponding data table at the end of the cores section. The corresponding core without air gap (dimension g = 0) must be ordered along with the gapped core (dimension g) to obtain the specified AL value.

Technical attributes (type, dimension g, AL value, material type): B66335G1500X127, 1.5 mm, 364 nH, N27

Technical specifications
Width 27.8 mm
Height 21 mm
Length 55 mm
Material N27
Air gap 1.5 mm
AL value 364 nH
Core shape E
Logistics
Country of origin CZ
Customs tariff number 85049011
Original Packaging Tray with 108 pieces
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
