B65671T0250G048 | TDK (EPCOS)
P core kit, N48, 250 nH, ±3 %, outer Ø 26 mm, inner Ø 21.2 mm, (H) 16.3 mm, B65671T0250G048
Unit Price (€ / pc.)
6.0571 € *
Available: 513 pcs.
Total Price:
6.06 € *
Price list
Quantity
Price per unit*
1 pcs.
6.0571 €
10 pcs.
5.3193 €
50 pcs.
4.9623 €
200 pcs.
4.6767 €
400 pcs.
4.4863 €
*incl. VAT plus shipping costs
Subject to prior sale
Core kits P 26 x 16, type TDK/Epcos B65671.
To IEC 60133. Made of silicon ferrite materials; refer to the corresponding data table at the end of the cores section; Design: gapped. Type D with center hole, type T with threaded sleeve, type W without center hole.
Technical attributes (type, AL value, material): B65671T250G48, 250 nH, N48
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Height | 16.3 mm | |
| Material | N48 | |
| Tolerance | ±3 % | |
| AL value | 250 nH | |
| Core shape | P | |
| Outer diameter | 26 mm | |
| Inner diameter | 21.2 mm | |
| Air gap | 0.4 mm |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Tray with 200 pieces |
| Customs tariff number | 85049011 |
| Country of origin | CZ |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
