B65651D0000R048 | TDK (EPCOS)
P core, N48, 2800 nH, -20/+30 %, outer Ø 18.4 mm, inner Ø 14.9 mm, (H) 10.6 mm, B65651D0000R048
Unit Price (€ / pc.)
5.3788 € *
Available: 26 pcs.
Total Price:
5.38 € *
Price list
Quantity
Price per unit*
1 pcs.
5.3788 €
10 pcs.
3.6890 €
100 pcs.
2.3919 €
500 pcs.
2.2729 €
1000 pcs.
2.2015 €
*incl. VAT plus shipping costs
Subject to prior sale
Without air gap, type B65651
according to IEC 60133. Made of silicon ferrite materials
Design: gapped. Type D with center hole, type T with threaded sleeve, type W without center hole.
Technical attributes (type, AL value, material): B65651DR48, 2800 nH, N48
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Inner diameter | 14.9 mm | |
| Air gap | no air gap | |
| AL value | 2800 nH | |
| Tolerance | -20/+30 % | |
| Height | 10.6 mm | |
| Outer diameter | 18.4 mm | |
| Material | N48 | |
| Core shape | P |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85049011 |
| Country of origin | CZ |
| Original Packaging | Bulk with 500 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
