B43644B9337M080 | TDK (EPCOS)

Name: Electrolytic capacitor, 330 µF, 400 V (DC), ±20 %, radial, pitch 10 mm, Ø 30 mm, B43644B9337M080
Brand: TDK (EPCOS)
SKU: 45D8077
Availability: InStock

Electrolytic capacitor, 330 µF, 400 V (DC), ±20 %, radial, pitch 10 mm, Ø 30 mm, B43644B9337M080

Order No.: 45D8077

EAN: 4099879876683

MPN:

B43644B9337M080

B43644B9337M80

Image may differ

Key Specification:

Version polar

Capacity 330 µF

Rated voltage (DC) 400 V

Tolerance ±20 %

Download Datasheet Technical specifications

Unit Price (€ / pc.)

5.7715 € *

Standard delivery time from the manufacturer is: 22 Weeks

Total Price:

1,846.88 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Electrolytic capacitor, B43644B9337M080, EPCOS

Aluminum electrolytic capacitor - Snap-in capacitor

Features

Extremely high CV product, very compact
High rated capacitance
High reliability and high ripple current capability
RoHS-compatible

Applications

Frequency converters
Solar inverters
Uninterruptible power supplies
Medical appliances

Technical specifications

Filter	Property	Value
	Grid	10 mm
	Ripple current	1 A
	min. operating temperature	-40 °C
	max. operating temperature	105 °C
	Version	polar
	Connection	snap-in
	diameter	30 mm
	Rated voltage (DC)	400 V
	Tolerance	±20 %
	Capacity	330 µF
	ESR (Equivalent Series Resistance)	280 mΩ
	Design	radial
	Length	35 mm
