B43544F2827M060 | TDK (EPCOS)

Name: Electrolytic capacitor, 820 µF, 250 V (DC), ±20 %, radial, pitch 10 mm, Ø 30 mm, B43544F2827M060
Brand: TDK (EPCOS)
SKU: 45D7752
Availability: InStock

Electrolytic capacitor, 820 µF, 250 V (DC), ±20 %, radial, pitch 10 mm, Ø 30 mm, B43544F2827M060

Order No.: 45D7752

EAN: 4099879876324

MPN:

B43544F2827M060

B43544F2827M60

Image may differ

Key Specification:

Version polar

Capacity 820 µF

Rated voltage (DC) 250 V

Tolerance ±20 %

Download Datasheet Technical specifications

Unit Price (€ / pc.)

5.4502 € *

Standard delivery time from the manufacturer is: 22 Weeks

Total Price:

1,744.06 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Electrolytic capacitor, B43544F2827M060, EPCOS

Aluminum electrolytic capacitor - Snap-in capacitor

Features

Extremely high CV product, very compact
Very high ripple current capability
High reliability
Very low ESR at operating conditions above 50 °C

Applications

Servo drives
Frequency converters
Solar inverters
Medical appliances

Technical specifications

Filter	Property	Value
	Grid	10 mm
	Ripple current	2 A
	min. operating temperature	-40 °C
	max. operating temperature	105 °C
	Version	polar
	Connection	snap-in
	diameter	30 mm
	Rated voltage (DC)	250 V
	Tolerance	±20 %
	Capacity	820 µF
	ESR (Equivalent Series Resistance)	85 mΩ
	Design	radial
	Length	35 mm
