B43541B7826M062 | TDK (EPCOS)
Electrolytic capacitor, 82 µF, 550 V (DC), ±20 %, radial, pitch 10 mm, Ø 30 mm, B43541B7826M062
Order No.: 45D7641
EAN: 4099879876096
MPN:
B43541B7826M062
B43541B7826M62
Unit Price (€ / pc.)
3.213 € *
Standard delivery time from the manufacturer is: 22 Weeks
Electrolytic capacitor, B43541B7826M062, EPCOS
Aluminum electrolytic capacitor - Snap-in capacitor
Features
- Voltage derating enables 105 °C operation
- Rated capacitance 82 µF
- High reliability and high ripple current capability
- Rated voltage 550 V DC
Applications
- Servo drives
- Frequency converters
- Solar inverters
- Uninterruptible power supplies
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 10 mm | |
| Ripple current | 870 mA | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Version | polar | |
| Connection | snap-in | |
| diameter | 30 mm | |
| Rated voltage (DC) | 550 V | |
| Tolerance | ±20 % | |
| Capacity | 82 µF | |
| ESR (Equivalent Series Resistance) | 1.62 Ω | |
| Design | radial | |
| Length | 25 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | HU |
| Original Packaging | Carton with 80 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
