B43509B9157M080 | TDK (EPCOS)

Name: Electrolytic capacitor, 150 µF, 400 V (DC), ±20 %, radial, pitch 10 mm, Ø 25 mm, B43509B9157M080
Brand: TDK (EPCOS)
SKU: 45D7549
Availability: InStock

Electrolytic capacitor, 150 µF, 400 V (DC), ±20 %, radial, pitch 10 mm, Ø 25 mm, B43509B9157M080

Order No.: 45D7549

EAN: 4099879876041

MPN:

B43509B9157M080

B43509B9157M80

Image may differ

Key Specification:

Version polar

Capacity 150 µF

Rated voltage (DC) 400 V

Tolerance ±20 %

Download Datasheet Technical specifications

Unit Price (€ / pc.)

3.332 € *

Standard delivery time from the manufacturer is: 22 Weeks

Total Price:

1,532.72 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Electrolytic capacitor, B43509B9157M080, EPCOS

Aluminum electrolytic capacitor - Snap-in capacitor

Features

Extremely high CV product, very compact
High rated capacitance
High reliability
RoHS-compatible

Applications

Frequency converters
Solar inverters
Uninterruptible power supplies
Medical appliances

Technical specifications

Filter	Property	Value
	Grid	10 mm
	Ripple current	880 mA
	min. operating temperature	-40 °C
	max. operating temperature	105 °C
	Version	polar
	Connection	snap-in
	diameter	25 mm
	Rated voltage (DC)	400 V
	Tolerance	±20 %
	Capacity	150 µF
	ESR (Equivalent Series Resistance)	530 mΩ
	Design	radial
	Length	30 mm
