B43509A9686M060 | TDK (EPCOS)
Electrolytic capacitor, 68 µF, 400 V (DC), ±20 %, radial, pitch 10 mm, Ø 25 mm, B43509A9686M060
Order No.: 17D0508
EAN: 4099879873767
MPN:
B43509A9686M060
B43509A9686M 60
Unit Price (€ / pc.)
2.3681 € *
Standard delivery time from the manufacturer is: 20 Weeks
Electrolytic capacitor, B43509A9686M060, EPCOS
Aluminum electrolytic capacitor - Snap-in capacitor
Features
- High CV product
- High rated capacitance
- High reliability
- Low ESR
Applications
- Frequency converters
- Solar inverters
- Uninterruptible power supplies
- Medical appliances
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 10 mm | |
| diameter | 25 mm | |
| ESR (Equivalent Series Resistance) | 1.2 Ω | |
| Connection | snap-in | |
| Rated voltage (DC) | 400 V | |
| max. operating temperature | 105 °C | |
| Tolerance | ±20 % | |
| Length | 25 mm | |
| Capacity | 68 µF | |
| min. operating temperature | -40 °C | |
| Ripple current | 510 mA | |
| Design | radial | |
| Version | polar |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Carton with 160 pieces |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
