B41456B9109M000 | TDK (EPCOS)
Electrolytic capacitor, 10000 µF, 100 V (DC), ±20 %, can, pitch 22.2 mm, Ø 51.6 mm, B41456B9109M000
No longer available from manufacturer
Unit Price (€ / pc.)
30.0237 € *
Available: 64 pcs.
Total Price:
30.02 € *
Price list
Quantity
Price per unit*
1 pcs.
30.0237 €
5 pcs.
27.7984 €
10 pcs.
26.2276 €
25 pcs.
24.7401 €
50 pcs.
23.5620 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor in aluminum can, type TDK/Epcos B41456.
With screw connections and insulated can, compliant with IEC 60384-4
Rated voltage 100 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 22.2 mm | |
| Ripple current | 10 A | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Version | polar | |
| Connection | screw connection | |
| diameter | 51.6 mm | |
| Rated voltage (DC) | 100 V | |
| Tolerance | ±20 % | |
| Capacity | 10000 µF | |
| ESR (Equivalent Series Resistance) | 18 mΩ | |
| Design | can | |
| Length | 80.7 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | HU |
| Original Packaging | Carton with 36 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
