B41456B8339M000 | TDK (EPCOS)
Electrolytic capacitor, 33000 µF, 63 V (DC), ±20 %, can, pitch 22.2 mm, Ø 51.6 mm, B41456B8339M000
Not suitable for new designs
Unit Price (€ / pc.)
29.2026 € *
Standard delivery time from the manufacturer is: 1 Week
Electrolytic capacitor, B41456B8339M000, EPCOS
Aluminum electrolytic capacitor - Screw terminal capacitor
Features
- High ripple current capability
- Long useful life
- High reliability
- All-welded construction ensures reliable electrical contact
Applications
- General industrial electronics
- For switch-mode power supplies in professional equipment
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 22.2 mm | |
| diameter | 51.6 mm | |
| ESR (Equivalent Series Resistance) | 6 mΩ | |
| Connection | screw connection | |
| Rated voltage (DC) | 63 V | |
| max. operating temperature | 85 °C | |
| Tolerance | ±20 % | |
| Length | 105.7 mm | |
| Capacity | 33000 µF | |
| min. operating temperature | -40 °C | |
| Ripple current | 14 A | |
| Design | can | |
| Version | polar |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | HU |
| Original Packaging | Carton with 36 pieces |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
