B41231C8478M000 | TDK (EPCOS)
Electrolytic capacitor, 4700 µF, 63 V (DC), ±20 %, radial, pitch 10 mm, Ø 30 mm, B41231C8478M000
Not suitable for new designs
Unit Price (€ / pc.)
2.499 € *
Standard delivery time from the manufacturer is: 13 Weeks
Electrolytic capacitor in aluminum can, type TDK/Epcos B41231.
Insulated can with snap-in connection, high AC current compatibility, to IEC 60384-4
Rated voltage 63 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 10 mm | |
| diameter | 30 mm | |
| Connection | snap-in | |
| Rated voltage (DC) | 63 V | |
| max. operating temperature | 85 °C | |
| Tolerance | ±20 % | |
| Length | 35 mm | |
| Capacity | 4700 µF | |
| min. operating temperature | -40 °C | |
| Ripple current | 4.1 A | |
| Design | radial | |
| Version | polar |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Original Packaging | Carton with 80 pieces |
| Customs tariff number | 85322200 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
