B41231C6688M000 | TDK (EPCOS)
Electrolytic capacitor, 6800 µF, 50 V (DC), ±20 %, radial, pitch 10 mm, Ø 30 mm, B41231C6688M000
Not suitable for new designs
Unit Price (€ / pc.)
3.9270 € *
Available: 248 pcs.
Total Price:
3.93 € *
Price list
Quantity
Price per unit*
1 pcs.
3.9270 €
10 pcs.
3.4986 €
50 pcs.
3.1416 €
150 pcs.
2.8560 €
500 pcs.
2.6180 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor in aluminum can, type TDK/Epcos B41231.
Insulated can with snap-in connection, high AC current compatibility, to IEC 60384-4
Rated voltage 50 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 85 °C | |
| Grid | 10 mm | |
| Tolerance | ±20 % | |
| Connection | snap-in | |
| min. operating temperature | -40 °C | |
| diameter | 30 mm | |
| Version | polar | |
| Capacity | 6800 µF | |
| Length | 35 mm | |
| Design | radial | |
| Ripple current | 4.92 A | |
| Rated voltage (DC) | 50 V |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85322200 |
| Original Packaging | Carton with 80 pieces |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
