B41231A8228M000 | TDK (EPCOS)

Electrolytic capacitor, 2200 µF, 63 V (DC), ±20 %, radial, pitch 10 mm, Ø 22 mm, B41231A8228M000

Order No.: 15D2626
EAN: 4099879873231
MPN:
B41231A8228M000
B41231A8228M
Series: B41231
B41231A8228M000 TDK (EPCOS) Electrolytic Capacitors Image 1
B41231A8228M000 TDK (EPCOS) Electrolytic Capacitors Image 2
Image may differ

Not suitable for new designs

Unit Price (€ / pc.)
2.6775 € *
Available: 191 pcs.
Total Price:
2.68 € *
Price list
Quantity
Price per unit*
1 pcs.
2.6775 €
10 pcs.
2.2372 €
100 pcs.
1.9159 €
250 pcs.
1.7374 €
1000 pcs.
1.5946 €
*incl. VAT plus shipping costs
Subject to prior sale

Electrolytic capacitor in aluminum can, type TDK/Epcos B41231.

Insulated can with snap-in connection, high AC current compatibility, to IEC 60384-4

Rated voltage 63 VDC.

Technical specifications
Filter Property Value
max. operating temperature 85 °C
diameter 22 mm
Rated voltage (DC) 63 V
Version polar
Grid 10 mm
Ripple current 2.5 A
Capacity 2200 µF
Connection snap-in
Tolerance ±20 %
min. operating temperature -40 °C
Design radial
Length 30 mm
Logistics
Property Value
Country of origin CN
Customs tariff number 85322200
Original Packaging Carton with 320 pieces
Compliance
Property Value
SVHC free Yes
RoHS conform Yes
Date of RoHS guidelines 3/31/15
