B41231A4109M000 | TDK (EPCOS)
Electrolytic capacitor, 10000 µF, 16 V (DC), ±20 %, radial, pitch 10 mm, Ø 22 mm, B41231A4109M000
Not suitable for new designs
Unit Price (€ / pc.)
1.9992 € *
Available: 453 pcs.
Total Price:
6.00 € *
Price list
Quantity
Price per unit*
3 pcs.
1.9992 €
15 pcs.
1.7493 €
75 pcs.
1.5589 €
400 pcs.
1.3923 €
800 pcs.
1.3209 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor in aluminum can, type TDK/Epcos B41231.
Insulated can with snap-in connection, high AC current compatibility, to IEC 60384-4
Rated voltage 16 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 10 mm | |
| Ripple current | 3.32 A | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Version | polar | |
| Connection | snap-in | |
| diameter | 22 mm | |
| Rated voltage (DC) | 16 V | |
| Tolerance | ±20 % | |
| Capacity | 10000 µF | |
| Design | radial | |
| Length | 25 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | CN |
| Original Packaging | Carton with 160 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
