B78476A8065A003 | TDK (EPCOS)
LAN module, 1:1, 350 µH, B78476A8065A003
Order No.: 74D6222
EAN: 4099889049114
MPN:
B78476A8065A003
B78476A8065A3
Unit Price (€ / pc.)
1.5946 € *
Standard delivery time from the manufacturer is: 24 Weeks
Magnetics module, B78476A8065A003, TDK
Magnetics module for LAN applications, single port with ferrite toroid, case and potting.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. operating temperature | 85 °C | |
| Length | 12.7 mm | |
| Winding ratio | 1:1 | |
| min. operating temperature | -40 °C | |
| Height | 5.6 mm | |
| Inductance | 350 µH | |
| Width | 7.11 mm | |
| min. frequency | 100 kHz | |
| Design | SMD | |
| Product type | LAN module | |
| max. frequency | 100 MHz |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85043180 |
| Original Packaging | Bulk with 500 pieces |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
