70064K | Talema

Toroidal flat transformer, 25 VA, 18 V, 18 V, 2x115 V, Talema 70064K

Order No.: 38C840
EAN: 4099891351137
MPN:
70064K
Series: 700
Talema
70064K Talema Toroidal Transformers Image 1
70064K Talema Toroidal Transformers Image 2
Image may differ
Print
Key Specification:
Output power 25 W
Primary voltage 2 x 115 V
Secondary voltage (1) 18 V
Secondary voltage (2) 18 V

Ordering Information:

Supplied with mounting accessories
Show variants: 20
Download Datasheet Technical specifications
Unit Price (€ / pc.)
23.6810 € *
Next delivery: 26 pcs. on 2026-06-19
Total Price:
852.52 € *
*incl. VAT plus shipping costs
Subject to prior sale
36 pcs.
23.6810 €
Description
Technical specifications
Download
Logistics
Compliance
Variations

Toroidal low-profile transformers, with UL certification, type Talema 700.

For ultra compact space and weight saving installation, excellent temperature response and only minute leakage field

Rated power 25 VA, type 7006.
Technical specifications
Output power 25 W
Primary voltage 2 x 115 V
Secondary voltage (1) 18 V
Secondary voltage (2) 18 V
Secondary amperage 1 0.694 A
secondary amperage 2 0.694 A
efficiency 83 %
Length 60 mm
Width 60 mm
Height 37.5 mm
Articles of same specification 0
Logistics
Customs tariff number 85043180
Country of origin IN
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
